The Bramidan 3-x 12 is suitable for smaller retail shops, industrial companies or other companies, who need a compact bale press with high capacity.
The compact design makes it ideal where space is limited. Equipped with double scissor cylinders, this machine offers superior press force but also a very low overall height.
The Bramidan 3-X 12 has a relatively large filling opening, making the daily operation as easy as possible.
If you would like to know more about the Bramidan 3-X 12 or any of our range of Vertical Balers please contact us.
| Bale Dimensions W x D x H (mm) | 800 x 600 x 600 |
| Bale weight cardboard approx. (kg) | 80-100 |
Bramidan 3-X12 baler technical data
|
| Model | 3-X (12) |
|---|---|
| Press force (t) | 12 |
| Power supply | 2×230/400V 50Hz 25/16A |
| Motor (kW) | 4.0 |
| Noise level (dB) | 68 |
| Cycle time (sec) | 18 |
| Dimensions WxDxH (mm) | 1245 x 775 x 1890 |
| Weight (kg) | 835 |
| Filling opening WxH (mm) | 715 x 715 |
| Filling height (mm) | 735 |
| Chamber height (mm) | 1230 |
| Stroke (mm) | 780 |
| Bale size WxDxH (mm) | 800 x 600 x 600 |
| Bale weight cardboard approx (kg) | 80-100 |
| Bale weight plastic approx (kg) | 100-120 |
Width
1200 Height
1100 Depth
800
Bale Weight 2500kg
Noise Level 71dB
Compaction Force 50 ton
Cycle Time 23 secs
1 YR Warranty
Width
770 Height
500 Depth
600
Bale Weight 310kg
Noise Level 65-68db
Compaction Force 3 ton
Cycle Time 18 secs
1 YR Warranty
Width
1010 Height
2890 Depth
1090
Bale Weight 640kg
Noise Level 70-75dB
Compaction Force 16 ton
Cycle Time 45 secs
1 YR Warranty
Width
800 Height
600 Depth
670
Bale Weight 80-110kg
Noise Level 59dB
Compaction Force 10 ton
Cycle Time 15 secs
Low Height 2 YR Warranty
Width
1200 Height
800 Depth
840
Bale Weight 200-250kg
Noise Level 59dB
Compaction Force 20 ton
Cycle Time 23 secs
Low Height 2 YR Warranty
