Kenburn-Select-KS400-Static-Compactor

Kenburn Select KS400 Static Compactor

, ,

The Kenburn Select KS400 static compactor is designed for handling large quantities of waste materials. It is manufactured with a large charge box and can be fed manually or using a bin lift, or alternatively, it can be loaded with a forklift truck or via a chute.
The KS400 Series comprises single and twin ram waste compactors. They have been specifically manufactured to work with high volume waste operations where large bulky materials may be loaded with loading shovels or grabs. The equipment is ideally suited to work with local Civic Amenity Sites and Transfer Stations.

QUICK SPECS

Machine Weight 2100 kg
Charge Box Length 1900 mm
Charge Box Width 1500 mm
View More

FINANCE OPTIONS

  • Purchase
  • Rent

CONDITION

  • New
Let's Talk
X

Technical Info

  • Available as either single or twin ram configuration
  • Cycle time of 38 seconds, or 48 secs for the twin ram
  • Charge box length: 1500mm x height: 1900mm

Technical Summary

Model KS400 single ram
Compaction force (t) 40 (40019kg/f)
Power supply 415 V 3 phase 32 amp isolator with 5 pin CEE socket, 3 phase neural and earth
Control Voltage (V) 110
Motor (kW) 11
Cycle time (sec) approx 38
Reservoir capacity (l) 200
Charge Box L x H mm) 1900 x 1500
Overall dimensions Lx W x H (mm) 5100 x 1610 x 1380
Loading height (mm) 1280
Cylinder bore (mm) 160
RAM Penetration (mm) 500
Blade height (mm) 740
Weight (kg) 2100
Model KS400 twin ram
Compaction force (t) 65 (65438kg/f)
Power supply

415 V 3 phase

32 amp isolator with 5 pin CEE socket, 3 phase neutral and earth

Control Voltage (V) 110
Motor (kW) 18
Cycle time (sec) approx 47
Reservoir capacity (l) 450
Charge Box L x H mm) 2000 x 1500
Overall dimensions Lx W x H (mm) 5100 x 1750 x 1380
Loading height (mm) 1280
Cylinder bore (mm) 2 x 180
RAM Penetration (mm) 500
Blade height (mm) 740
Weight (kg)

Additional Info

Robust Construction

UK-flagDesigned and manufactured in the UK for Kenburn, the single ram KS400 compactor has a compaction force of 40 tonnes, while the twin ram has a force of over 65 tonnes.

They are well engineered and robustly constructed and powered by an 11 kw, or in the case of the twin ram compactor an 18kw hydraulic power pack.
