Bramidan X16 Vertical Baler
Key features of the X16 Baler
- High compression for dense bales
- Silent hydraulic system ensures minimal disruption to your work environment
- Extremely simple and safe to use
This Baler is equipped with cross cylinders to deliver higher press force coupled with stable compression for superb results. Combined with a long stroke a high bale weight can be achieved.
This Baler is designed with easy servicing in mind, for example the positioning of the hydraulic unit next to the control panel on the side of the machine, for easy access.
Bramidan X16 Technical Data Bramidan X16 Technical Drawing
Technical Specification Summary
| Model | X16 | |
| Press force (t) | 16 | |
| Power supply | 3x230/400V 50Hz 25/16A | |
| Motor (kW) | 4.0 | |
| Noise level (dB) | 67 | |
| Cycle time (sec) | 22 | |
| Dimensions WxDxH (mm) | 1715 x 1290 x 1995 | |
| Weight (kg) | 1260 | |
| Filling opening WxH (mm) | 1090 x 530 | |
| Filling height (mm) | 950 | |
| Chamber height (mm) | 1375 | |
| Stroke (mm) | 955 | |
| Bale size WxDxH (mm) | 1200 x 800 x 800 | |
| Bale weight cardboard (kg) | 150-250 | |
| Bale weight plastic (kg) |
200-300 |
If you would like to know more about our waste management products, the X16 or any of our Vertical Baler range please contact us.
